6.0 inch 4G Smart Android POS Printer widely used for restaurant ordering system, parking system, bus ticketing, airtime top up, cryptocurrency projects ect.
6.0 inch 4G Smart Android POS Printer Introduction
TW-Q5 is 6.0 inch high resolution screen Android POS terminal with 1D/2D image engine option.
It widely used for restaurant ordering system, parking system, bus ticketing, airtime top up, cryptocurrency projects ect.
6.0 inch 4G Smart Android POS Printer Feature
Android 8.1（4G veriosn）, Android 6.0 (3G version)
6.0inch 1440*720 high resolution screen
2G/3G/4G communication for Optional;
50mm diameter big paper roll.
2G RAM+16G Storage, can be extend to 2+32G.
Built-in high speed 58mm thermal printer module;
Built-in 8 megapixels camera;
Built-in large volume speaker;
Support 32GB TF card extended memory;
1D/2D image engine scanner for optional;
NFC (HF) function for optional;
Support 12V DC interface charging;
7.4V, 5000mAh large capacity battery.
6.0 Inch 4G Smart Android POS Printer Specification
|
Specification |
||
|
Processor |
||
|
* |
CPU |
ARM Cortex-A17 Quad-core, 1.3GHz |
|
System Android 8.1（4G veriosn）, Android 6.0 (3G version) |
||
|
Feature |
||
|
* |
Structural style |
Semi-cut plate |
|
* |
Outline dimension |
230*88.6*23.8 mm |
|
* |
Screen size |
6.0 inch HD 720*1440，IPS |
|
* |
Touch screen |
Capacitance screen, multi-touch |
|
* |
Button |
Power button+ Scanning button+ Volume addition button+ Volume subtraction button |
|
* |
Battery |
7.4V 5000mAh |
|
* |
Memory |
16GB ROM + 2GB RAM(Standard version) |
|
* |
Camera |
Rear camera 8 million pixels, support autofocus, audio recording at the same time |
|
* |
Multimedia |
Audio support MP3、 AAC、OGG ect； Video support MP4、 H.263、H.264 ect. |
|
* |
GPS |
support |
|
* |
AGPS |
support |
|
* |
WIFI |
2.4G supportIEEE802.11 b/g/n/ac |
|
* |
Bluetooth |
Support Bluetooth 2.1/3.0/4.0，support BLE |
|
* |
Charging interface |
DC12V 1.5A |
|
* |
Headphone interface |
support |
|
* |
USB interface |
Mini USB2.0 |
|
* |
Loudspeaker |
1W/8R |
|
* |
Sensor |
G-Sensor、Light Distance Sensor、Fingerprint（Option） |
|
* |
NFC |
Support TypeA、TypeB、M1 |
|
* |
Professional Scanner |
1D/2D（Option） |
|
Radio frequency specification |
||
|
* |
Type |
GSM/GPRS/WCDMA |
|
* |
WCDMA bands |
WCDMA B1(2100)MHz B5(850)MHz B8(900)MHz |
|
* |
GSM SIM bands |
850/900/1800/1900MHz |
|
* |
FDD-LTD |
B1/B3/B5/B7/B8/B20 |
|
* |
TDD-LTD |
B38/B39/B40/B41 |
|
* |
|
|
|
USIM |
||
|
* |
USIM |
support |
|
* |
SIM card |
2pcs slot |
|
|
||
