SZTW-CR8300 is 2 in 1 CPU contact IC chip card and 13.56mhz high frequency proximity RFID card reader writer . It supports to read Thailand identification citizen card easily with our software. There are 4 SAM card slot options, it’s widely used for banking, government department system.The following is about 2 In 1 Contact Chip And RFID Contactless Smart Card Reader Writer related, I hope to help you better understand 2 In 1 Contact Chip And RFID Contactless Smart Card Reader Writer.
2 In 1 Contact Chip And RFID Contactless Smart Card Reader Writer
Introduction of 2 In 1 Contact Chip And RFID Contactless Smart Card Reader Writer
SZTW-CR8300 is 2 in 1 CPU contact IC chip card and 13.56mhz high frequency proximity RFID card reader writer . It supports to read Thailand identification citizen card easily with our software. There are 4 SAM card slot options, it’s widely used for banking, government department system.
Feature of 2 In 1 Contact Chip And RFID Contactless Smart Card Reader Writer
-2 LED Status Indicators -USB 2.0 Full Speed Device (HID)
-Compatible with Windows、Linux、Android4.0+ -Protocol: ISO/IEC 14443 TypeA、TypeB(Option)、ISO/IEC 15693（Option）
-Card type: Mifare Std 1K、Mifare Std 4K、Mifare Desfire EV1、UltraLight、
-Mifare Pro card、TypeA CPU card、TypeB CPU（Option）、Icode2（Option）
-Provide SDK/API for further development and integration. -118mm (L) x 78mm (W) x 18mm (H), 150g
Thailand ID card reading case by TW-CR8300
Specification of 2 In 1 Contact Chip And RFID Contactless Smart Card Reader Writer
| Host Interface | |
| Interface | USB 2.0 Full Speed Device (HID) Humans Input Device |
| Power | From USB port |
| Supported Operating Systems | Windows® XP, Windows® 7, Windows® 8.1, Windows® 10, Linux®, Android |
| Contact card interface (optional up to 1) | |
| Support protocol | ISO7816 (T = 0 & T = 1) |
| Support card type | Support ISO7816 standard, T = 0, T = 1 CPU card, all common memory cards, Thailand Identification chip card, Logical encryption cards, such as 4442, 4428, 24C series cards, AT88SC102, AT88SC1604, AT88SC1608, |
| Operation card parameters | Support card voltage: 5V, 3V, 1.8V; Support card speed: 9600-115200bps |
| Contactless Smart Card Interface | |
| Standard | ISO/IEC 14443 TypeA, TypeB (Optional), ISO/IEC 15693 (Optional) |
| Support the card type | Mifare ® Classic Protocols card, UltraLight, UltraLight C, T=CL CPU card, Ntag213, Ntag215, Ntag216, I-CODE2 (Optional)、Mifare Desfire EV1、UltraLight、Mifare Pro card、TypeA CPU card、TypeB CPU（Option） |
| Operating Distance | Up to 50 mm |
| Output Format | |
| Format | 10 digit dec(Defoult output format) (Allow user to customize the output format by software) |
| Built-in Peripherals | |
| Buzzer | Monotone |
| LED Status Indicators | 2 LED (green and red) |
| Physical Specifications | |
| Dimensions | 118mm (L) x 78mm (W) x 18mm (H) |
| Weight | 150g |
| Operating Conditions | |
| Temperature | 0°C – 60°C |
| Humidity | 10% to 90%, non-condensing |
