Magnetic RFID Contactless Card Reader Writer allows you to make secure payments anytime and anywhere with Smartphones and Tablets.
Magnetic RFID Contactless Card Reader Writer Introduction
Magnetic RFID Contactless Card Reader Writer Feature
-Convenient& easy: USB interface, boot self-checking. No additional power supply, don‘t need to install the driver, plug&play
-State tip: the built-in buzzer, have two LED lights. Green LED light indicator card read is successful
-Read &write: Support magnetic card reading, and proximity contactless RFID card reading writing function.
-Security features: Built-in data encryption options: triple DES, advanced security features.
-Standard: Compatibility standards such as ISO, AAMVA, CADMV
-Card type: Support domestic the most widely used MIFARE ONE card
-Technical advantages: To provide the complete dynamic library functions, provide perfect examples of development, the key points, and a variety of development language call example source code (including: 2003 c #, c + + builder, Adelphi, original concept, VB.net 2003, VB6.0 by use of Java)
Magnetic RFID Contactless Card Reader Writer Specification
|
Electrical |
|
|
Power suplly |
Via USB port |
|
Current |
45~65mA |
|
Interconnection |
|
|
Interface |
USB2.0、USB-OTG(Android 3.1 above) |
|
Mechanical |
|
|
Body |
ABS |
|
Dimensions |
100mm(L)X34mm(W)X30mm(H) |
|
Weight |
90g |
|
Color |
Black |
|
Environment |
|
|
Operation temp |
-20℃ ~ 55 ℃ |
|
Operation humidity |
10%~90% relative humidity |
|
Storage temp |
-30℃~70℃ |
|
Storage humidity |
10%~90% relative humidity |
|
Magnetic card |
|
|
Selectable tracks |
yes |
|
Read card |
1/2/3 tracks |
|
Swipe |
Double direction |
|
Head life |
Approx 500,000 passes |
|
Parity and LRC checking |
Built-in, audible and LED good read and error indicator |
|
Cards supported |
ISO 7811,AMMVA,CADMV |
|
RFID card |
|
|
Operating Frequency |
13.56 MHz |
|
Smart Card Interface |
ISO14443-A, Mifare |
|
Sensing Distance |
0-5cm |
|
Programmable sound |
ON or OFF |
|
Cards supported |
SO 14443A,Mifare One S50,Mifare One S70,Mifare One Mini,Mifare Ultra Light,Desfire,Mifare Plus |
|
Operation |
|
|
Operating Systems |
Win7, Win 2008 ,Vista, Win 2003, Win 2000, XP, Linux |
|
Certifications |
CE, FCC, UL, ROHS |
